HBONY high quality Multi Screen Video Wall with Industrial HD&High-brightness panel
Advantages of LCD Video Wall
♦ Reliable quality and low maintenance: Less thermal diffusivity makes the components and parts more stable.
♦ High Definition and clear image: High brightness and contrast make colors brilliant and bright, as well as stable and clear image.
♦ Wide viewing angle: DID LCD panel makes the viewing angle up to 180°.
♦ Low power consumption and low heat radiation
♦ Long service life lowers the cost of usage and maintenance
♦ Innovative and advanced: 42” to 60” Ultra thin bezel LCD video wall, the thinnest bezel up to 1.8mm
♦ Ultathin and lightweighted: The ultra thin and lightweighted design makes it easy to transport and install.
♦ Economic al and practical: High performance and high quality make it cost less.
| LCD Video Wall |
| Model No. | HBY-PJ460P |
| Panel Size | 46" LCD Screen |
| Backlight Type | LED |
| Display Area | 1018(H)x572(V)mm |
| Aspect Ratio | 16:9 |
| Max Resolution | 1920*1080 |
| Color | 8Bit,16.7M |
| Brightness (nits) | 700cd/m2 |
| Contrast | 4000:1 |
| Visual Angle (H/V) | 178 ° |
| Response Time | 8 ms |
| Life Span | >60,000 hours |
| Bezel width (between screens) | 3.5mm |
| Product Dimension | 1021.98(L)×576.57(H)×125.7(D) |
| Product Weight | 26KG |
| Input | 1*DVI |
| 1*HDMI |
| 2* BNC |
| 1*VGA (SVGA / XGA / WXGA) |
| 2*RS232(RJ45) |
| Output | 2* BNC |
| 2*RS232(RJ45) |
| Power |
| Power Supply | AC100V~240V 50/60Hz |
| Maximum Power Consumption | 180W |
| Stanby Power Consumption | <3W |
| Working Environment |
| Working Temperature | 10℃~60℃ |
| Working Humidity | 10%-95%RH |
LCD-DID Industrial HD&High-brightness narrow edge LCD.
Narrow Edge Design: Minimum 3.5mm.
High Resolution Ratio: 1920*1080
High-brightness: 500cd/sqm
Super wide visual angle:178(H)/178(V)
Digital information display with LCD-DID Industrial HD&High-brightness narrow edge LCD.
Built-in splicing module, Support splice function,support Creating one window(PIP) across the screen,roaming service,scaling,PIP Support matrix joint control.
Unique DNX motion supplement image processing technology, Dynamic image without motion
trail,Splicing image processing RS-232(RJ-45)loop-circuit input/output.,Input by remote control with wire,mobile receiver head.
